Broadband Dielectric Mirror
High Reflectivity, Ravg>99.5%, AOI 0-45deg
Wide Working Band
RoHS Compliant
We can manufacture lenses in any optical material required. Please contact us with your specific requirements,Custom lenses are available on request.
General specifications
Dimension Tolerance
+/-0.02mm
Thickness Tolerance
+/-0.02mm
Surface Quality
20/10
Clear Aperture
>90%
Flatness
<λ/10@632.8nm per 25mm range
Chamfer
Protective<0.5mmx45°
Coating
Dielectric HR coating on one surface, Ravg>99.5% for random polarization, AOI 0-45deg, rear surface ground or inspection polished
Damage Threshold
>5J/cm2, 20ns, 20Hz, @1064nm
